Gear lever handles |
GN 310 |
| Type A Ball knob DIN 319 | Type C Taber knob GN 419 | Type E Cylindrical knob GN 519 |
| d1 | Length l1 | d2 | d3 | d5 | d7 | l2 | l3 | l5 | l7 | ||
| A | C | E | A | C | E | ||||||
| 8 | 63 | 80 | 100 | M 6 | 20 | 20 | 18 | 9 | 18 | 30 | 40 |
| 10 | 80 | 100 | 125 | M 8 | 25 | 25 | 21 | 11 | 22,5 | 38 | 50 |
| 12 | 100 | 125 | 160 | M 10 | 32 | 30 | 23 | 14 | 29 | 46 | 65 |
| 14 | 125 | 160 | 200 | M 12 | 35 | 35 | 26 | 16 | 32,5 | 53 | 80 |
| 16 | 160 | 200 | 250 | M 14 | 40 | 35 | 28 | 18 | 37 | 53 | 90 |
| Specification | Information | How to order |
| Shafts Steel blackened
Knobs |
The choice of knobs can be made dependant on their function and / or their modern design. | Gear lever handle GN 310-10-125-E
Code No. 310 |
|
|
|
